- Multi-purpose 2″ pump
- Designed for pumping industrial and agricultural chemicals
- Easy starting Honda OHV commercial engine
- 220 gal./min capacity
- Thermoplastic pump housing for chemical capability
- Designed for pumping industrial and agricultural chemicals: See the applications tab for approved chemical applications.
- Easy starting Honda OHV commercial engine: The durable Honda GX series commercial grade engine is easy starting and provides ample power for the toughest conditions.
- EPDM seals for chemical resistance: The WMP20 features EPDM seals, a type of rubber material that is designed to be compatible with a wide range of chemicals.
- 220 gal./min capacity
- Thermoplastic components for chemical capability: The WMP20’s reinforced thermoplastic housing, volute & impeller improve chemical resistance.
- Isolation mounted engine and pump: High performance mounts minimize vibration, keeping the pump from “walking” away or “burying” itself in soft soil conditions. The reduced vibration also reduces wear on components, increasing the pump’s durability.
- Heavy duty full frame protection: Protects the pump, while offering a convenient tie down location for transport.
- Protected by Honda Oil Alert®: Protects the pump by shutting the engine off when low oil is detected.
- 3 year residential/commercial warranty: You can rest easy, knowing your pump is covered from top to bottom for 3 full years.
- Engine: GX160
- Displacement: 163cc
- Bore and stroke: 2.7 in. x 1.8 in.
- Compression Ratio: 9.0:1
- Oil Alert: Std
- Pump type: Multi-purpose Centrifugal Self-priming
- Volute: Rigid Mounted Fiberglass reinforced polyester
- Impeller: Fiberglass reinforced polyester
- Mechanical Seal (Pump case / impeller): Carbon/Ceramic
- Priming time: 65 sec. @ 16.4 ft.
- Drive system: Direct
- Discharge capacity: 220 gpm
- Suction port diameter: 2 in. NPT
- Discharge port diameter: 2 in. NPT
- Total head lift: 102 ft.
- Suction head lift: 26 ft.
- Maximum pressure: 44 psi
- Solids handling: N/A
- Dimensions (LxWxH): 20.5 in. x 15.7 in. x 17.7 in.
- Dry weight: 57 lb.
- Fuel Capacity: 0.82 gal.
- Run Time @ Max Discharge: 1.5 hr
- Strainer Part #: 78325-YE0-003
- Residential Warranty: 3 years
- Commercial Warranty: 3 years
- A wide variety of hose kits, couplers, adaptors, and other accessories are available.
